Model: FDQ-B04
Voltage: AC220~240V 50Hz
Built fuse: T2A
Digital input format: DMX 512 / RDM
Control: The power supply switch
Signal path: 2 way in and 4 way out, photoelectric coupling isolation protection
Installation: hanging type, hanging and fixed type installation
Power supply hand in hand: AC IN input / AC OUT Connect to the next one
Indicator: the normal signal green indicator light is always on, and the signal abnormal green indicator light is off
Power consumption of the whole machine: less than 10W
RDM: with the RDM signal feedback
USB: 2-way 5 VUSB input port
Wiring mode: 3 +, 2-, 1 shielding
Signal amplification and transmission distance: 4,200 meters
Color: black + blue + silver
Dimensions: 310 * 70 * 76mm
Weight: 1.45kg
Use: 4 independent amplified DMX signal output, effectively improve the DMX signal transmission ability, effectively improve the DMX signal anti-disturbance ability, DMX signal photoelectric isolation effectively prevent the city high voltage string into the dimming platform, prevent lightning into the high voltage string into the dimming platform hand-in-hand power input is convenient for the use of multiple machines
Configuration: three-core power plug * 5, three-core power plug * 1,16A power plug * 1,16A power plug * 1
