Model: FDQ-04
Power supply: AC90V~240V, 50Hz / 60Hz, 15W
Digital signal type: DMX 512 / 1900 communication protocol standard
Signal connection socket: input XLR-3-M and output XLR-3-F
Signal input and output: 1 signal input, 1 direct signal output, 8 signal distribution output through electrical isolation
Color: black + red
Dimensions: 484 * 45 * 140mm
Weight: 2kg
Pressure resistance: input to output electrical isolation pressure resistance> AC 300W
Function: 8Ch independently amplified DMX signal output, effectively improve the DMX signal transmission ability and signal anti-interference ability
